EXPRESCUT SSMA CUTTING
CONSUMABLES FOR CUTTING (STANDARD)
CONSUMABLE KIT CONTENT
CODE Ø PT2105
105 A
•
1 CV0387P 21,3 mm 1

2 PC0370P 34,8 mm • 1
3 PD0402P15 1,5 mm 0,059” 17,5 mm • 5
•
4 PE0362P 23 mm 1

5 PR0362P 29,5 mm • 5

CODE CODE
cable assembly - 6 m / 19.7’
6 FH1716P air tube 2 11 PH4172-06 - 1/4 G - Central adaptor 1
cable assembly - 12m / 39.4’
7 EA1920 o-ring 5 11 PH4172-12 - 1/4 G - Central adaptor 1
cable assembly - 6 m / 19.7’
7 PF1391 torch head 1 11 PH4173-06 1
- 1/4 G - Trafimector
cable assembly - 12m / 39.4’
7 PT0366 microswitch kit 1 11 PH4173-12 - 1/4 G - Trafimector 1
protection shell kit
9 TP0321 for torch head 1 12 FY0043 plasma central adaptor - 5 pins 1
tube handle TRAFIMECTOR® central adaptor
10 TP0322 with spring support 1 12 FY0090 - torch side 1

STANDARD
