MIG WELDING traf imet.com

MIG
CONTACT TIPS

CODE REF
MD0001-06 M5 - Cu M5 0,6 mm .023” 18 mm 23/32 - 20
MD0001-08 M5 - Cu M5 0,8 mm .030” 18 mm 23/32 TOPS 100V - 20
MD0001-09 M5 - Cu M5 0,9 mm .035” 18 mm 23/32 - 20
MD0001-10 M5 - Cu M5 1,0 mm .040” 18 mm 23/32 - 20

MD0003-08 1/4-28 UNF - CU 1/4-28 UNF 0,8 mm .030” 38 mm 1”-1/2 14-30 20
MD0003-09 1/4-28 UNF - CU 1/4-28 UNF 0,9 mm .035” 38 mm 1”-1/2 MAXI 250 14-35 20
MEGA 2
MD0003-10 1/4-28 UNF - CU 1/4-28 UNF 1,0 mm .040” 38 mm 1”-1/2 T 2 14-40 20
MD0003-12 1/4-28 UNF - CU 1/4-28 UNF 1,2 mm .045” 38 mm 1”-1/2 14-45 20

MD1003-08 1/4-28 UNF - Triangolar CU 1/4-28 UNF 0,8 mm .030” 38 mm 1”-1/2 MAXI 250 - 20
MD1003-10 1/4-28 UNF - Triangolar CU 1/4-28 UNF 1,0 mm .040” 38 mm 1”-1/2 MEGA 2 - 20
MD1003-12 1/4-28 UNF - Triangolar CU 1/4-28 UNF 1,2 mm .045” 38 mm 1”-1/2 T 2 - 20
MD0004-08 1/4-28 UNF - CU 1/4-28 UNF 0,8 mm .030” 37,4 mm 1”-15/32 14H30 20
MD0004-09 1/4-28 UNF - CU 1/4-28 UNF 0,9 mm .035” 37,4 mm 1”-15/32 MAXI 350 14H35 20
MD0004-10 1/4-28 UNF - CU 1/4-28 UNF 1,0 mm .040” 37,4 mm 1”-15/32 MEGA 4 14H40 20
MD0004-12 1/4-28 UNF - CU 1/4-28 UNF 1,2 mm .045” 37,4 mm 1”-15/32 T-MEGA 4 14H45 20
MD0004-14 1/4-28 UNF - CU 1/4-28 UNF 1,4 mm .052” 37,4 mm 1”-15/32 T 4 14H52 20
MD0004-16 1/4-28 UNF - CU 1/4-28 UNF 1,6 mm 1/16” 37,4 mm 1”-15/32 14H116 20

MD1004-08 1/4-28 UNF - Triangolar CU 1/4-28 UNF 0,8 mm .030” 37,4 mm 1”-15/32 MAXI 350 - 20
MD1004-10 1/4-28 UNF - Triangolar CU 1/4-28 UNF 1,0 mm .040” 37,4 mm 1”-15/32 MEGA 4 - 20
MD1004-12 1/4-28 UNF - Triangolar CU 1/4-28 UNF 1,2 mm .045” 37,4 mm 1”-15/32 T-MEGA 4 - 20
MD1004-16 1/4-28 UNF - Triangolar CU 1/4-28 UNF 1,6 mm 1/16” 37,4 mm 1”-15/32 T 4 - 20

MD0005-08 M8 - Cu M8 0,8 mm .030” 30 mm 1”-3/16 140.0114 20
MD0005-09 M8 - Cu M8 0,9 mm .035” 30 mm 1”-3/16 PLUS 400 - 20
MD0005-10 M8 - Cu M8 1,0 mm .040” 30 mm 1”-3/16 PLUS 500 140.0313 20
MD0005-12 M8 - Cu M8 1,2 mm .045” 30 mm 1”-3/16 PLUS 555 140.0442 20
PLUS 600
MD0005-14 M8 - Cu M8 1,4 mm .052” 30 mm 1”-3/16 PLUS 601 - 20
MD0005-16 M8 - Cu M8 1,6 mm 1/16” 30 mm 1”-3/16 MAXI 450 140.0587 20
MD0005-20 M8 - Cu M8 2,0 mm 5/64” 30 mm 1”-3/16 MAXI 4000 140.0653 20
MD0005-24 M8 - Cu M8 2,4 mm 3/32” 30 mm 1”-3/16 140.0677 20

MD0005-38 M8 - Cu-Ni M8 0,8 mm .030” 30 mm 1”-3/16 PLUS 400 - 20
MD0005-40 M8 - Cu-Ni M8 1,0 mm .040” 30 mm 1”-3/16 PLUS 500 - 20
PLUS 555
MD0005-42 M8 - Cu-Ni M8 1,2 mm .045” 30 mm 1”-3/16 PLUS 600 - 20
MD0005-44 M8 - Cu-Ni M8 1,4 mm .052” 30 mm 1”-3/16 PLUS 601 - 20
MAXI 450
MD0005-46 M8 - Cu-Ni M8 1,6 mm 1/16” 30 mm 1”-3/16 MAXI 4000 - 20
MD0005-58 M8 - Cu for aluminium M8 0,8 mm .030” 30 mm 1”-3/16 PLUS 400 141.0003 20
MD0005-60 M8 - Cu for aluminium M8 1,0 mm .040” 30 mm 1”-3/16 PLUS 500 141.0008 20
MD0005-62 M8 - Cu for aluminium M8 1,2 mm .045” 30 mm 1”-3/16 PLUS 555 141.0015 20
PLUS 600
MD000566 M8 - Cu for aluminium M8 1,6 mm 1/16” 30 mm 1”-3/16 PLUS 601 141.0022 20
MD0005-70 M8 - Cu for aluminium M8 2,0 mm 5/64” 30 mm 1”-3/16 MAXI 450 - 20
MD0005-74 M8 - Cu for aluminium M8 2,4 mm 3/32” 30 mm 1”-3/16 MAXI 4000 - 20
