traf imet.com MIG WELDING

CODE REF
EN60974-7 quick release nozzle
1 MC0568 16 mm 5/8” 76 mm 3” - 10
- 2,5 mm thickness
2 MD0009-10 M6 - Cu 1,0 mm .040” 28 mm 1”-3/32 140.0242 20

3 MD0061-00 M6 - brass 22 mm 7/8” 142.0007 20
4 ME0585 ceramic 29 mm 1”-5/32 018.0141 10

20 GM0510 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 3 m 10’ 124.0026 1
20 GM0511 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 4 m 12’ 124.0031 1

20 GM0512 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 5 m 16,4’ 124.0035 1

*Complete list of available consumables at the end of this section

CODE CODE
5 MF1518 Ergoplus 26 torch head 1 8 MH0818-050 coaxial cable - 5 m / 16.4’ 1
6 MT0563 trigger kit 1 9 AR0070 EURO connector - air 1

7 MT0562 handle kit 1 9 BW0020 metal EURO nut 10

7 MT0566 pistol grip 1 9 FA0026 liner nut M10x1 10
8 MH0818-030 coaxial cable - 3 m / 10’ 1 9 MT0565 back box kit EURO 1

8 MH0818-040 coaxial cable - 4 m / 16.4’ 1

STANDARD
