traf imet.com MIG WELDING

CODE REF
EN60974-7
1 MC0023 nozzle 15 mm 19/32’’ 57 mm 2-1/4’’ 145.0076 10

2 MD0009-10 M6 - Cu 1,0 mm .040” 28 mm 1’’-3/31 140.0242 20

4 ME0016 M6 - copper 35 mm 1° 3/8 142.0001 10
20 GM0510 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 3 m 10’ 124.0026 1

20 GM0511 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 4 m 12’ 124.0031 1
20 GM0512 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 5 m 16.4’ 124.0035 1

*Complete list of available consumables at the end of this section

CODE CODE
5 FB0947-SP brass body 1 7 MT0592 handle kit 1

5 EA0304 neck spring 10 7 MT0566 pistol grip 1
5 MF1530-SP Ergoplus 25R torch head 45° 1 8 MH0817-030 coaxial cable - 3 m / 10’ 1

5 MF1531-SP Ergoplus 25R torch head L 45° 1 8 MH0817-040 coaxial cable - 4 m / 12’ 1

5 MF1532-SP Ergoplus 25R torch head XL 45° 1 8 MH0817-050 coaxial cable - 5 m / 16.4’ 1
5 EA1930-SP spring kit 5 9 AR0070 EURO connector - air 1

5 BW0595-SP bush kit 3 9 BW0020 metal EURO nut 10

5 BW0594-SP nut kit 3 9 FA0026 liner nut M10x1 10
6 MT0563 trigger kit 1 9 MT0565 back box kit EURO 1

CODE X Y Z(°)
MF1530-SP 108 75 45

MF1531-SP 158 75 45

MF1532-SP 208 75 45

STANDARD
