traf imet.com MIG WELDING

CODE REF
EN60974-7
1 MC0023 nozzle 15 mm 19/32’’ 57 mm 2-1/4’’ 145.0076 10

2 MD0009-10 M6 - Cu 1,0 mm .040” 28 mm 1’’-3/31 140.0242 20

4 ME0016 M6 - copper 35 mm 1° 3/8 142.0001 10
20 GM0510 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 3 m 10’ 124.0026 1

20 GM0511 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 4 m 12’ 124.0031 1
20 GM0512 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 5 m 16.4’ 124.0035 1

20 GM0514 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 6m 19.6’ 1

20 GM0543 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 8m 26.2’ 1

*Complete list of available consumables at the end of this section

CODE CODE
5 BW0562 plastic body 1 8 MH0817-050 coaxial cable - 5 m / 16.4’ 1

5 EA0304 spring 10 8 MH0817-060 coaxial cable - 6 m / 19.6’ 1

5 MF1517 Ergoplus 25 torch head 1 8 MH0817-080 coaxial cable - 8 m / 26.2’ 1
6 MT0563 trigger kit 1 9 AR0070 EURO connector - air 1

7 MT0562 handle kit 1 9 BW0020 metal EURO nut 10
7 MT0566 pistol grip 1 9 FA0026 liner nut M10x1 10

8 MH0817-030 coaxial cable - 3 m / 10’ 1 9 MT0565 back box kit EURO 1

8 MH0817-040 coaxial cable - 4 m / 12’ 1

STANDARD
