traf imet.com MIG WELDING

CODE REF
EN60974-7
1 MC0301 nozzle 17 mm 1/2” 63,5 mm 2-1/2” 145.0062 10

2 MD0008-10 M6 - Cu 1,0 mm .040” 25 mm 31/32” 140.0253 20

3 MD0138-00 M6 - brass 26 mm 1° 1/32” 142.0003 20
4 ME0584 ceramic 20 mm 25/32” - 10

20 GM0510 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 3 m 10’ 124.0026 1
20 GM0511 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 4 m 12’ 124.0031 1

20 GM0512 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 5 m 16.4’ 124.0035 1

*Complete list of available consumables at the end of this section

CODE CODE
5 MF1516 Ergoplus 24 torch head 1 8 MH0817-050 coaxial cable - 5 m / 16.4’ 1
6 MT0563 trigger kit 1 9 AR0070 EURO connector - air 1

7 MT0562 handle kit 1 9 BW0020 metal EURO nut 10

7 MT0566 pistol grip 1 9 FA0026 liner nut M10x1 10
8 MH0817-030 coaxial cable - 3 m / 10’ 1 9 MT0565 back box kit EURO 1

8 MH0817-040 coaxial cable - 4 m / 12’ 1

STANDARD

All trademarks are exclusive property of the respective companies. Data and images are indicative and may be changed in any time without notice. Trafimet Group SpA 81
