CODE REF
1 MC0018 nozzle 12 mm 1/2” 53 mm 2-1/16” 145.0075 10

2 MD0008-08 M6 - Cu 0,8 mm .030” 25 mm 31/32” 140.0059 20

20 GM0500 blue steel liner 0,6 ÷ 0,9 mm .023” ÷ .035” 3 m 10’ 124.0011 1
20 GM0501 blue steel liner 0,6 ÷ 0,9 mm .023” ÷ .035” 4 m 12’ 124.0012 1

20 GM0502 blue steel liner 0,6 ÷ 0,9 mm .023” ÷ .035” 5 m 16.4’ 124.0015 1

*Complete list of available consumables at the end of this section

CODE CODE
5 FB0947-SP brass body 1 7 MT0566 pistol grip 1
5 EA0303 diffuser spring 10 8 MH0816-030 coaxial cable - 3 m / 10’ 1

5 FB0117 diffuser 10 8 MH0816-040 coaxial cable - 4 m / 12’ 1
5 MF1535-SP Ergoplus 15R torch head 45° 1 8 MH0816-050 coaxial cable - 5 m / 16.4’ 1

5 EA1930-SP spring kit 5 9 AR0070 EURO connector - air 1

5 BW0595-SP bush kit 3 9 BW0018 euro nut plastic 10
5 BW0594-SP nut kit 3 9 FA0026 liner nut M10x1 10

6 MT0563 trigger kit 1 9 MT0565 back box kit EURO 1

7 MT0592 handle kit 1

STANDARD

All trademarks are exclusive property of the respective companies. Data and images are indicative and may be changed in any time without notice. Trafimet Group SpA 77
