PLASMA CUTTING
EXPRESCUT S

CONSUMABLES FOR CUTTING (CONTACT)

CODE Ø CONTACT DRAG GOUGING REF
1 CV0299 gouging shield 20,8 mm • 2

1 CV1118 stand off guide 25,5 mm • 2
•
2 PC0098 nozzle 29 mm 2
•
2 PC0198 long life nozzle 29 mm 2
3 PD0098-08 40 A 0,8 mm .030” 17,7 mm • 10

3 PD0098-10 60 A 1,0 mm .040” 17,7 mm • 10
•
3 PD0199-16 gouging tip 1,6 mm .063” 17,7 mm 10
• •
4 PE0106 Swirl ring 4,6 mm 60028 2

5 PR0098 electrode 24,8 mm • • 10

CONSUMABLES FOR DRAG

CODE Ø CONTACT DRAG GOUGING REF
•
1 CV0298 stand off guide 37,9 mm 2
2 PC0198 long life nozzle 29 mm • 2
•
3 PD0198-08 40 A 0,8 mm .030” 18 mm 10
•
3 PD0198-10 60 A 1,0 mm .040” 18 mm 10
4 PE0106 Swirl ring 4,6 mm • 60028 2

5 PR0106 electrode 30,5 mm • 10

CODE CODE
coaxial cable - 6 m / 19.7’
7 EA0330 o-ring 10 10 PH4027 - 1/4 G (no pin) 1
7 PF0128 S65 torch head 1 11 BW0147 cable support 10

8 TP0310 trigger kit 1 11 FY0023 plasma central adaptor - 5 pins 1
TRAFIMECTOR® central
9 TP0301 handle kit 1 12 FY0090 adaptor - torch side 1
9 BW0424 spring joint 10 EA0254 pin extractor for central adaptor 1

PT0202 male spring pins kit (5 pcs) 1

STANDARD CONTACT SHORT CONTACT LONG DRAG SHORT DRAG LONG GOUGING
