PLASMA CUTTING
EXPRESCUT S

CODE Ø CONTACT DRAG GOUGING REF
743.0149
0618.
1 CV0010 stand off 18,5 mm • 0408-2053 10
guide
stand off
1 CV0024 guide 23,5 mm 33 mm • 1
nozzle
2 PC0116 (no ring) 28 mm • • • 60389 4

3 PD0102-08 30 A 0,8 mm .030” 13,3 mm • 10
3 PD0102-10 50 A 1,0 mm .040” 13,3 mm • 10
•
3 PD0103-09 40 A 0,9 mm .035” 25,8 mm 10
•
3 PD0103-65 20 A 0,65 mm .025” 25,8 mm 10
3 PD0116-06 20 A 0,6 mm .023” 17,3 mm • 10

3 PD0116-08 30 A 0,8 mm .030” 17,3 mm • 10
•
3 PD0116-09 40 A 0,9 mm .035” 17,3 mm 10
• • •
4 PE0106 Swirl ring 4,6 mm 2
5 PR0105 electrode 17,8 mm • 10
5 PR0106 electrode 30,5 mm • 60028 10

•
5 PR0110 electrode 21,8 mm 10

CODE CODE
cable assembly - 4 m / 12’
7 EA0330 o-ring 10 10a PH4127 - 1/4 G 1
S25K - S35K - S25 - S45
7 PF0127 torch head 1 11 BW0147 cable support 10
8 TP0310 trigger kit 1 11 FY0023 plasma central adaptor - 5 pins 1
TRAFIMECTOR® central
9 TP0301 handle kit 1 12 FY0090 adaptor - torch side 1
9 BW0424 spring joint 1 EA0254 pin extractor for central adaptor 1
coaxial cable - 6 m / 19.7’
10 PH4027 - 1/4 G (no pin) 1 PT0202 male spring pins kit (5 pcs) 1

STANDARD CONTACT SHORT CONTACT LONG DRAG SHORT DRAG LONG GOUGING
