MIG WELDING
EXPRESCUT S

CODE Ø REF
1 MC0603-SP nozzle 16 mm 5/8” 84 mm 3” 5/16 - 10

1 FB0903-SP vacuum nozzle 40 mm 1” 9/16 56 mm 2” 7/32 - 1

1 EA2070 locking spring 36,5 mm 1” 7/16 - - - 3
1 FB0901-SP locking bush 36 mm 1” 13/32 30,5 mm 1” 3/16 - 1

1 FB0945 vacuum tube 36,7 mm 1” 7/16 93 mm 3” 21/32 - 1
2 MD0005-78 M8 - CuCrZr 0,8 mm .030” 30 mm 1”-3/16 - 20
2 MD0005-80 M8 - CuCrZr 1,0 mm .040” 30 mm 1”-3/16 140.0316 20
2 MD0005-82 M8 - CuCrZr 1,2 mm .045” 30 mm 1”-3/16 140.0445 20
2 MD0005-84 M8 - CuCrZr 1,4 mm .052” 30 mm 1”-3/16 140.0536 20
2 MD0005-86 M8 - CuCrZr 1,6 mm 1/16” 30 mm 1”-3/16 140.0590 20
2 MD0005-90 M8 - CuCrZr 2,0 mm 5/64” 30 mm 1”-3/16 140.0656 20
2 MD0005-94 M8 - CuCrZr 2,4 mm 3/32” 30 mm 1”-3/16 - 20
3 MD0063-00 M6 - brass 28 mm 1”-3/32 142.0005 20

3 MD0064-00 M8 - brass 28 mm 1”-3/32 142.0020 20

3 MD0131-00 M6 - brass 32 mm 1”-1/4 142.0011 20
3 MD0132-00 M8 - brass 32 mm 1”-1/4 142.0024 20

4 ME0017 plastic 32,8 mm 1”-9/32 014.0261 10

4 ME0041 plastic 32,8 mm 1”-9/32 014.0021 10
4 ME0417 high-tech plastic 32,8 mm 1”-9/32 - 10

4 ME0517 ceramic 32,8 mm 1”-9/32 014.0023 10

20 GM0874 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 3 m 10’ - 1
20 GM0875 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 4 m 12’ - 1

20 GM0876 red steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 5 m 16.4’ - 1

CODE CODE

5 MF1522 Ergofresh 350G torch head 1 8 MQ0388-030 spare leather cover kit - Velcro® 1
3 m / 10’
6 MT0563 trigger kit 1 8 MQ0388-040 spare leather cover kit - Velcro® 1
4 m / 12’
spare leather cover kit - Velcro®
7 MT0568 handle kit 1 8 MQ0388-050 1
5 m / 16.4’
7 MT0566 pistol grip 1 9 MT0569 vacuum box kit 1
8 MH0821-030 coaxial cable - 3 m / 10’ 1 9 MT0572 back box spring kit 1

8 MH0821-040 coaxial cable - 4 m / 12’ 1 9 MT0570 back box kit Euro - air 1

8 MH0821-050 coaxial cable - 5 m / 16.4’ 1 9 AR0070 EURO connector - air 1
8 MQ0127-030 outer cover kit - 3 m / 10’ 1 9 BW0020 metal EURO nut 10

8 MQ0127-040 outer cover kit - 4 m / 12’ 1 9 FA0026 liner nut M10x1 10

8 MQ0127-050 outer cover kit - 5 m / 16.4’ 1

STANDARD
