CODE REF
EN60974-7 quick release nozzle
1 MC0568 16 mm 5/8” 76 mm 3” - 10
- 2,5 mm thickness
2 MD0005-82 M8 - CuCrZr 1,2 mm .045” 30 mm 1”-3/16 140.0445 20

3 ME0390 M8 - copper 25 mm 31/32” - 10
4 ME0579 ceramic 16 mm 5/8” 28 mm 1”-3/32 - 10

20 GM0530 uncoated steel liner 1,2 ÷ 1,6 mm .045” ÷ 1/16” 3 m 10’ 1
20 GM0531 uncoated steel liner 1,2 ÷ 1,6 mm .045” ÷ 1/16” 4 m 12’ 1

20 GM0532 uncoated steel liner 1,2 ÷ 1,6 mm .045” ÷ 1/16” 5 m 16.4’ 1

*Complete list of available consumables at the end of this section

CODE CODE
5 FB1278 Insulator 10 7 MT0593 handle kit 1
5 MG0301-SP Ergoplus 500R torch head 50° 1 7 MT0566 pistol grip 1

5 MG0302-SP Ergoplus 500R torch head 30° 1 8 MN2018-030-SP cable assembly - 3 m / 10’ 1

5 MG0303-SP Ergoplus 500R torch head 50° L 1 8 MN2018-040-SP cable assembly - 4 m / 12’ 1
5 MG0304-SP Ergoplus 500R torch head 30° L 1 8 MN2018-050-SP cable assembly - 5 m / 16.4’ 1

5 MG0305-SP Ergoplus 500R torch head 50° XL 1 9 AR0110-SP EURO connector 1
5 MG0306-SP Ergoplus 500R torch head 30° XL 1 9 BW0020 metal EURO nut 10

6 MT0594 trigger kit 1 9 FA0026 liner nut M10x1 10
9 MT0564 back box kit 1

CODE CODE CODE
8a BX1422-030-SP 3 m / 10’ 8a BX1422-040-SP 4 m / 12’ 8a BX1422-050-SP 5 m / 16.4’
b Wire and gas conduit 8b MH1262-030-SP 3 m / 10’ 8b MH1262-040-SP 4 m / 12’ 8b MH1262-050-SP 5 m / 16.4’
8c QB0076 3 m / 10’ 8c QB0077 4 m / 12’ 8c QB0078 5 m / 16.4’
8d QA0019 3 m / 10’ 8d QA0020 4 m / 12’ 8d QA0021 5 m / 16.4’
8f MQ0125-030 3 m / 10’ 8f MQ0125-040 4 m / 12’ 8f MQ0125-050 5 m / 16.4’

CODE X Y Z(°)
MG0301-SP 146 94 50

MG0302-SP 170 66 30

MG0303-SP 196 94 50
MG0304-SP 220 66 30

MG0305-SP 306 94 50

MG0306-SP 330 66 30
