MIG WELDING
traf imet.com MIG WELDING

CODE REF
EN60974-7
1 MC0301 nozzle 12,5 mm 1/2” 63,5 mm 2-1/2” 145.0080 10

2 MD0008-08 M6 - Cu 0,8 mm .030” 25 mm 31/32” 140.0059 20

3 MD0138-00 M6 - brass 26 mm 1° 1/32” 142.0003 20
4 ME0584 ceramic 20 mm 25/32” - 10

20 GM0526 uncoated steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 3 m 10’ 1
20 GM0527 uncoated steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 4 m 12’ 1

20 GM0528 uncoated steel liner 1,0 ÷ 1,2 mm .040” ÷ .045” 5 m 16.4’ 1

*Complete list of available consumables at the end of this section

CODE CODE
cable assembly - 5 m / 16.4’
5 MG0284 Ergoplus 240 torch head 1 8 MN2014-050 1
with ball-joints
6 MT0563 trigger kit 1 9 AR0052 EURO connector - air 1

7 MT0560 handle kit 1 9 BW0020 metal EURO nut 10

7 MT0566 pistol grip 1 9 FA0026 liner nut M10x1 10
cable assembly - 3 m / 10’
8 MN2014-030 1 9 MT0564 back box kit 1
with ball-joints
cable assembly - 4 m / 12’
8 MN2014-040 1
with ball-joints

CODE CODE CODE
8a BX1421-030 3 m / 10’ 8a BX1421-040 4 m / 12’ 8a BX1421-050 5 m / 16.4’
8b QB0231-030 3 m / 10’ 8b QB0231-040 4 m / 12’ 8b QB0231-050 5 m / 16.4’
8c QB0230-030 3 m / 10’ 8c QB0230-040 4 m / 12’ 8c QB0230-050 5 m / 16.4’
8d QB0232-030 3 m / 10’ 8d QB0232-040 4 m / 12’ 8d QB0232-050 5 m / 16.4’
8e QA0030-030 3 m / 10’ 8e QA0030-040 4 m / 12’ 8e QA0030-050 5 m / 16.4’
8f MQ0125-030 3 m / 10’ 8f MQ0125-040 4 m / 12’ 8f MQ0125-050 5 m / 16.4’

ST
STANDARD
AND
ARD
All trademarks are exclusive property of the respective companies. Data and images are indicative and may be changed in any time without notice. Trafimet Group SpA 99
