PLASMA CUTTING
EXPRESCUT S

CODE Ø CONTACT DRAG GOUGING REF

1 CV0008 stand off guide 32,5 mm • 51957 10
1 CV0009 stand off guide 38,6 mm • 10
•
1 CV0011 stand off guide 23 mm 1386 10
•
1 CV0012 stand off guide 30 mm 1408 2
1 CV0014 stand off guide 30 mm • 2

1 CV0021 stand off guide 32,8 mm 40,6 mm • 1
•
1 CV0023 stand off guide 17,6 mm 10
•
1 CV0039 stand off guide 18,5 mm 2

1 CV1105 stand off guide 30 mm • 10
•
1 CV1106 stand off guide 28 mm 10
•
2 BW0139 shield for CV1105 7,5 mm 10

2 BW0146 shield for CV1106 7,5 mm • 10
2 CV1107 stand off guide 17 mm • 10

2 FH0297 insulator for CV0039/ • • 10
CV0023
2 PC0120 long life nozzle 50,9 mm • • • 2

2 PC0131 long life nozzle 50,9 mm • • • • 2
3 PD0109-11 60 A 1,1 mm .043” 12,7 mm • • • • 10
3 PD0109-14 100 A 1,4 mm .055” 12,7 mm • • • • 10
3 PD0109-16 130 A 1,6 mm .063” 12,7 mm • • • • 10
3 PD0109-18 140 A 1,8 mm .071” 12,7 mm • • • • 10
3 PD0109-30 gouging tip 3,0 mm 1/8” 12,7 mm • 10
•
3 PD0111-12 80 A 1,2 mm .047” 35,8 mm 10
3 PD0117-14 100 A 1,4 mm .055” 34,8 mm • 10
3 PD0117-17 130 A 1,7 mm .066” 34,8 mm • 10
3 PD0117-19 140 A 1,9 mm .075” 34,8 mm • 10
4 PE0103 diffuser 7,8 mm • • • • • • • 2
• • • • •
5 PR0111 electrode 20,5 mm 10
• •
5 PR0116 electrode 43,1 mm 10
6 FH0563 air tube 29 mm • • • • • • • 1

CODE CODE
coaxial cable - 6 m / 19.7’
7 EA0131 O-ring Ø 19 x 2 mm 10 10a PH4020 - M14x1 1
7 PF0160 A151 torch head 1 11 BW0147 cable support 10
8 TP0310 trigger kit 1 11 FY0023 plasma central adaptor - 5 pins 1
TRAFIMECTOR® central
9 TP0303 handle kit 1 12 FY0090 adaptor - torch side 1

9 BW0424 spring joint 1 EA0254 pin extractor for central adaptor 1
coaxial cable - 6 m / 19.7’
10 PH4023 - 1/4 G (no pin) 1 PT0202 male spring pins kit (5 pcs) 1
STANDARD CONTACT SHORT CONTACT LONG DRAG SHORT DRAG LONG GOUGING
