PLASMA CUTTING
EXPRESCUT S

CODE Ø CONTACT DRAG GOUGING REF
• 743.0149
1 CV0010 stand off guide 18,5 mm 0618, 10
0408-2053
1 CV0073 stand off guide 24,2 mm 31 mm • 1

1 CV1117 stand off guide 26 mm • 1405 2
• •
2 PC0032 nozzle 31,5 mm 5710171 2
•
3 PD0063-10 50 A 1,0 mm .040” 26,8 mm 10
3 PD0063-11 60 A 1,1 mm .043” 26,8 mm • 10
3 PD0063-12 70 A 1,2 mm .047” 26,8 mm • 10
3 PD0085-98 50 A 0,98 mm .038” 26,2 mm • 1366 10
3 PD0088-08 40 A 0,8 mm .030” 12,3 mm • 10
3 PD0088-10 50 A 1,0 mm .040” 12,3 mm • 1396 10
3 PD0088-11 60 A 1,1 mm .043” 12,3 mm • 10
3 PD0088-12 70 A 1,2 mm .047” 12,3 mm • 1308 10

4 PE0007 diffuser 15,6 mm • • 20101 2
5 CV0081 tool for wear parts 1

5 PR0063 electrode 17,8 mm • 1402 10
5 PR0064 electrode 34,8 mm • 1403 10
•
6 FH0211 air tube 12 mm 1
•
6 FH0215 long air tube 20,5 mm 1

CODE CODE
7 9
7 10

7 10

8 10a
8 10a

9 11

9 11

STANDARD CONTACT SHORT CONTACT LONG DRAG SHORT DRAG LONG GOUGING
